Description
Features:
- Semi-open impellers permit passage of solids without clogging
- Heavy cast iron construction
- Stainless steel fasteners
- 416 stainless steel rotor shaft
- Permanently lubricated upper and lower ball bearings
- Oil-filled hermetically sealed motors with thermal overload protection
- Unitized carbon and ceramic shaft seal
- Dual-sized discharge flange: 1-1/2: or 2″
- Quick-disconnect power cord in 35 length.
Technical Specifications:
- Horsepower: 3/4 HP
- Oparation Type: Automatic
- Maximum Flow: 102 GPM @ 5′ head
- Maximum Head: 90 ft
- Discharge: 2″ FNPT (1-1/2” FNPT cast iron flange provided)
- Solids Handling: 3/4″
- Maximum Fluid Temperature: 140°F
- Cord Length: 35 ft
- Construction: Cast Iron
- Frequency of Revolutions: 3450 RPM
- Voltage: 208-230V
- Amperage: 10.5 A.
Warranty:
3 years manufacturer’s warranty
