BMI 09634 1/2″PEX x 3/8″OD Straight Stop – Chrome Plated Valve – 1/4 Turn – Lead Free

Description

BMI 09634 1/2″PEX x 3/8″OD Straight Stop – Chrome Plated Valve – 1/4 Turn – Lead Free

Features & Benefits:

• Forged brass with chrome plated body
• Quarter turn open & shut
• Self-lubricating P.T.F.E. seats
• Double O-ring for more safety
• Suitable for both plumbing and hydronic heating application

List of Materials:

• Body: C46500
• Bonnet: C46500
• Ball: C46500
• Seat: PTFE
• Stem: C46500
• O-Ring: EPDM
• Handle: ABS
• Screw: SS304
• Comp.Ring: H65 Brass
• Nut: C37700

Compliance:

• Certified By: IAPMO

• Complies With:

• ASME A112.18.1
• CSA B125.1-11
• F1807, F1960
• ANSI/NSF 61
• ANSI/NSF 372
• ANSI/NSF 14

Technical Downloads:

• BMI Lead Free Chrome Supply Valves: Specification Submital
• BMI Lead Free Chrome Supply Valves: Promotional Flyer
