About This Product
This 1/2 HP thermoplastic shallow well jet pump is designed for wells with water depths of 25 ft. or less. It comes equipped with a factory pre-wired 30/50 pressure switch and a pressure gauge for convenient monitoring. The corrosion-resistant thermoplastic housing is built to withstand everyday use.
Highlights
- Corrosion-resistant thermoplastic pump housing
- Designed for water depths up to 25 ft.
- Factory pre-wired 30/50 pressure switch
- Heavy-duty dual-voltage motor (115V/230V), preset to 230V
- 1 in. FNPT discharge and 1-1/4 in. FNPT inlet/suction connection
Specifications
| Product Depth (in.) | 9.45 in. |
| Product Height (in.) | 8.66 in. |
| Product Width (in.) | 21.02 in. |
| Amperage (A) | 12.4 A |
| Cord Length (ft.) | 0 ft. |
| Discharge Flow 0 ft. @ 40 PSI (gallons/hour) | 690 GPH |
| Discharge Flow 0 ft. @ 40 PSI (gallons/min) | 12 GPM |
| Discharge Flow 25 ft. @ 40 PSI (gallons/hour) | 330 GPH |
| Discharge Flow 25 ft. @ 40 PSI (gallons/min) | 6 GPM |
| Features | Corrosion Resistant, Self-Priming |
| Head Pressure (ft.) | 148 ft. |
| Housing Material | Thermoplastic |
| Impeller Material | Thermoplastic |
| Included | No Additional Items Included |
| Inlet Connection | Threaded female |
| Jet Pump Product Type | Shallow Well |
| Maximum Horsepower (HP) | 1/2 HP |
| Maximum Pressure (PSI) | 64 PSI |
| Maximum Working Temperature (F) | 95°F |
| Minimum working temperature (F) | 32°F |
| Outlet Connection | Threaded female |
| Pack Size | 1 |
| Product Weight (lb.) | 27.104 lb. |
| Pump Switch Type | Pressure |
| Returnable | 30-Day |
| Vertical Lift (ft.) | 25 ft. |
| Voltage | 115v, 230v |
| GTIN | 850052141851 |
