Zurn Wilkins 6″ 375ASTBG RPZ Backflow Preventer | Stainless Steel & Butterfly Valves.
Product Overview:
The Zurn Wilkins 6″ 375ASTBG RPZ Backflow Preventer provides large-capacity protection for potable water systems in high-flow applications. With a stainless steel body and supervised butterfly valves, this RPZ model offers code-compliant, lead-free backflow protection for industrial buildings, hospitals, and large campuses.
Features & Benefits:
-
High-capacity RPZ with two check valves and relief valve
-
Compact form allows installation in tight vaults
-
Stainless steel body resists chemicals and corrosion
-
NSF/ANSI 372 lead-free compliant for potable water
-
Grooved butterfly valves with supervision/tamper monitoring
-
In-line service without disconnecting system
-
Suitable for high-pressure installations
Specifications:
-
Size: 6″
-
Material: 304L Stainless Steel
-
Max Pressure: 175 PSI
-
Test Pressure: 350 PSI
-
Temperature Range: up to 140°F
-
Ends: Grooved or Flanged
-
Certifications: ASSE 1013, NSF 61/372, FM®, UL®, CSA®, IAPMO®
Installation Tips:
-
Install with ample clearance above grade and beside drains
-
Allow side access to test cocks and butterfly handles
-
Ensure butterfly valves are properly supervised if required by code
-
Always pressure test after installation
FAQs:
Q: Is this unit approved for fire systems?
A: Yes, it’s often used for combined domestic and fire protection water services.
Q: How do I access the internal components?
A: Remove the top cover to access check modules and the relief valve for in-line maintenance.
